The Tale of the "Sail"

A version of this painting, "The Fin-Back Lizards" (background: Dimetrodon incisivus, foreground: Naosaurus claviger) by Charles R. Knight, appeared in H.F. Osborn's obituary for E.D. Cope, The Century Magazine (1897). Public domain.
Prehistoric tetrapods are fascinating to young and old alike in large part due to their often unusual features. We have duck-billed hadrosaurids, mammoths with huge curving tusks, horned and frilled ceratopsids, plate-backed stegosaurids, and, famously, a variety of prehistoric animals with sails on their backs, like the dimetrodonts.

Sails are often said to be present in other prehistoric animals, like ouranosaurs, spinosaurs, and arizonasaurs, but these are not the quintessential "sails" present in early synapsids like edaphosaurs and dimetrodonts. In the former, the neural spines of the vertebrae are very tall, but also broad and flat, as in normal vertebral columns. These probably anchored muscles, and at the very least supported a ridge of thick soft tissue, not just skin. In dimetrodonts and edaphosaurs*, on the other hand, the neural spines are not just tall, but thin, round, and strut-like. These aren't the kind of vertebrae that would be wrapped in muscle, and may have supported only a thin membrane of skin (I'm not aware of any actual direct evidence for a skin membrane sail, but correct me if I'm wrong).

During the late 1800s, the anatomy and relationships of the sail-backed synapsids was not yet well understood. In a situation weirdly parallel to the famous story about Brontosaurus, the first skeletons of what are now known as Edaphosaurus were found lacking skulls. A small herbivorous skull was actually found first, and given the name Edaphosaurus, but the connection to the sail-backed body was not made until later.  The whole saga of Naosaurus, as the headless body was named, was told by Brian Switek at Laelaps. In short, the headless body of Edaphosaurus was seen by E.D. Cope as being very similar to Dimetrodon, and Cope referred a skull to it which is know known to belong to the smooth-spined form rather than the knobby-spined form. When it was discovered that is was actually the small, herbivorous heads already named Edaphosaurus belonged to the headless body, the name Naosaurus was sunk.

Skull attributed to Naosaurus claviger (but now to Dimetrodon) from Cope 1888, public domain.

The thing that interested me most about revisiting this story was the whole history of the term "sail" itself. Why were these synapsids referred to as "sail-backs", a term that has since spread to any prehistoric animal with long neural spines?

Many people are aware of the early speculation that sail-backed synapsids used their sails to, well, sail. That is, to literally use their tall dorsal fins to catch the wind and move across water. Most people nowadays also think back on this idea as rather silly. The dorsal fin "sails" were, of course, parallel to the body, like the configuration of a sloop. However, unlike the speculative use of large crests as sails in some pterosaurs, which could at least move the head and neck to change the orientation of the supposed sail, poor dimetrodonts and edaphosaurs would be consigned to getting dragged more or less laterally across the surface of the water. At best, the undulating swimming motion of the torso would cell catch some wind, but the resulting constant change and undulating motion of the sail itself seems like it would make steering very difficult. (Nonetheless, I'm certain I've seen an artistic rendition of this behavior somewhere).

Switek says in his blog post the same thing I and everyone else tend to assume about Cope's sailing hypothesis, which is that Cope suspected "the long spines had a membrane stretched between them and could be used to catch the wind, just like a sail".

But, that's not quite right. It's true that Naosaurus translates as "ship lizard", named for Cope's sail-back hypothesis. But this hypothesis seems to have been specific to Cope's ship lizard, not to the (he thought) closely related Dimetrodon. In fact, if you read some of Cope's original descriptions, you find that the only feature he thought separated Naosaurus from Dimetrodon was the presence of transverse processes on the neural spines. Those are the little thorny side-projections present on the sides of the edaphosaur sail, contrary to the smooth, spike-like bony projections that make up that of dimetrodonts.

Cope thought that it was these side projections, which, while most were broken at the base, he estimated would could be up to half the length of the main neural spine in some specimens, that actually anchored the membranes of the sail! Cope pictured edaphosaurs with a series of membranous sails perpendicular to the torso, not parallel to it, similar to the configuration of the rigging of a large sailing ship rather than a sloop. As Cope said,

"In a full-sized individual, the longest cross-arms, which are the lowest in position, have an expanse of two hundred and sixty millimeters, or ten and a quarter inches, while the spine has about the height of five hundred millimeters (19.75 inches), the body being 60 mm. long. The animal must have presented an extraordinary appearance. Perhaps the yard-arms were connected by membrane with the neural spine or mast, thus serving the animal as a sail, with which he navigated the waters of the Permian lakes." (Cope 1888, p. 294).

While many prehistoric animals are described as having sails, it's interesting to keep in mind that this term seems to first have come about based on a hypothesized structure that was very different from the comparatively "normal" dorsal fins and ridges we're used to seeing today. Cope himself seems to have given up on the idea by the time he was supervising Charles Knight in a restoration of Naosaurus,** which other than the Dimetrodon-like skull, appears relatively normal by modern standards. Still, a proper reconstruction of a truly mast-sailed edaphosaur would be a nice challenge for paleoartists...

*Interestingly, most phylogenetic analyses nowadays suggest that these two types of sail-backed synapsids do not form a natural group with each other. So either the sails evolved convergently, or they are a trait of the common ancestor of the two types of animal. Which would mean our own ancestors were sail-backs!
**Knight later revised his Naosaurus painting, removing the transverse processes altogether and giving it an actual Dimetrodon skull, modifying it into simply a restoration of a Dimetrodon.

References
* Cope, E. D. (1888). Systematic Catalogue of the Species of Vertebrata Found in the Beds of the Permian Epoch in North America with Notes and DescriptionsTransactions of the American Philosophical Society16(2), 285-297.
* Osborn, H. F. (1897). A Great NaturalistCentury Magazine, November.
